- • Low PIM
- • High Reliability
- • High Isolation
- • Simple Installation
Technical Data
|
Part Number |
|
GR05007 |
GR05008 |
GR05009 |
GR05010 |
GR05011 |
GR05012 |
GR05013 |
GR05014 |
GR05015 |
|
Electrical Specifications |
||||||||||
|
Frequency Range |
MHz |
380 - 470 |
||||||||
|
Coupler Value |
dB |
5 |
6 |
7 |
8 |
10 |
12 |
13 |
15 |
20 |
|
Accuracy |
dB |
±1.0 |
±1.0 |
±1.0 |
±1.0 |
±1.2 |
±1.5 |
±1.5 |
±1.5 |
±1.5 |
|
Insertion loss |
dB |
≤2.2 |
≤2.0 |
≤2.0 |
≤1.5 |
≤1.1 |
≤0.7 |
≤0.6 |
≤0.5 |
≤0.5 |
|
Isolation |
dB |
≥20 |
≥20 |
≥20 |
≥20 |
≥20 |
≥20 |
≥20 |
≥20 |
≥20 |
|
VSWR |
dB |
≤ 1.3 |
||||||||
|
Intermodulation (3rd |
dBc |
£ -150 @ 2 x 20 W |
||||||||
|
Average Power Handling |
W |
300 |
||||||||
|
Impedance |
W |
50±3 |
||||||||
|
Mechanical Specifications |
||||||||||
|
Connectors Type |
|
N Female |
||||||||
|
Dimension (Subject to |
mm |
179 x 37 x 19 (Connectors Included) |
||||||||
|
Net Weight (subject |
kg |
0.25 |
||||||||
|
Material |
|
Aluminum |
||||||||
|
Environmental Specifications |
||||||||||
|
Operating |
°C |
-15 to +60 |
||||||||
|
Relative Humidity |
% |
5 - 95 |
||||||||
|
Application |
|
IP56 |
||||||||
